Germany Wika agent stock pressure transmitter IL-10 pressure transducer IL-10 pressure sensor IL-10

Germany Wika agent stock pressure transmitter IL-10 pressure transducer IL-10 pressure sensor IL-10

Description

For the highest demands The intrinsically safe submersible pressure transmitter model IL-10 has been designed for the highest requirements of level measurement. Owing to their high accuracy, reliability and

their excellent media resistance, it is the ideal solution for almost all level measurements in hazardous areas. Especially noteworthy are the outstanding approval-related characteristics (CENELEC approval per ATEX). In addition, the IL-10 has the North-American approvals FM (USA) and CSA (Canada).

Output signal

Signal 4 ... 20 mA, 2-wire

Load in Ω

≤ (power supply - 10 V) / 0.02 A - (cable length in m x 0.14 Ω)

Voltage supply

Power supply DC 10 ... 30 V

Reference conditions

Temperature: 15 ... 25 °C (59 ... 77 °F)

Atmospheric pressure: 860 ... 1,060 mbar (12.5 ... 15.4 psi) Humidity: 45 ... 75 % r. h.

Mounting position: Calibrated in vertical mounting position

with process connection facing downwards. Power supply: DC 24 V
