| Storage temperature | -65 to 160°F (-54 to 71°C) |
| Ambient temperature limits |
-40 to 160°F (-40 to 71°C); models 520-525, 540-548, 700-706, 15731-15736: 0 to 160°F (-18 to 71°C); Set point typically shifts less than 1% of range for a 50°F (28°C) ambient temperature change |
| Set point repeatability |
Temperature models: ± 1% of adjustable range Pressure models 15623, 15731-15737, 171-174, 218, 270-376, 520-535, 540-543, 700- 706, 560-564: ± 1% of adjustable range; models 190-194, 183-189, 483-494, 544-548, 565-567, 610-680, 15884: ±1.5% of adjustable range Internal set point lock on all pressure models |
| Shock | Set point repeats after 15 G, 10 millisecond duration |
| Vibration | Set point repeats after 2.5 G, 5-500 Hz |
| Enclosure | Die cast aluminum, epoxy powder coated, gasketed, captive cover screws |
| Enclosure classification | Enclosure type 4X |
| Switch output | One SPDT snap action switch; switch may be wired “normally open” or “normally closed” |
| Electrical rating |
15A 125/250/480 VAC resistive except for H100-15623, 15731-15737, 15884, 20A 125/250/480 VAC resistive, B100-13546 and E100-13545, 22A/480 VAC. Electrical switches have limited DC capabilities at 24-30 VDC, 2A resistive and 1A inductive. 125 VDC, 0.5A resistive, 0.03A inductive. Consult factory for additional information. |
| Weight | 2-7 lbs; Varies with model |
| Electrical connection | 1/2” NPT (female); Two 7/8” diameter knockouts |
