UE differential pressure switch UE 24-011-M200-M201-M900

Product Name:*
Name:
E-mail:*
Message:*
UE differential pressure switch UE 24-011-M200-M201-M900

Features
• UL listed and cUL certified. CE compliant to low voltage directive and pressure equipment directive
• Vacuum, Pressure or Differential pressure measurement
• 5 A @ 125/250 VAC SPDT snap-acting switch
• External stainless steel multi-turn adjusting screw
• OEM capabilities include external adjustment knob with or without reference scale

Technology
The 24 Series (Delta Pro™) was designed to be a compact, cost-effective differential pressure switch for applications such as proof-of-flow, filter monitoring, etc. It depends upon two opposing diaphragms to sense pressure on the "High" and "Low" pressure outputs of a system. The resulting pressure differential is transmitted through a linkage to a snap-action electrical switch, providing an output when a pre-set difference is exceeded. This set point can be easily modified while under pressure via an external adjusting screw. This adjustment "pre-loads" the actuation mechanism, which results in excellent vibration-resistance. Straight pressure and vacuum versions, with a single diaphragm, are also available.
