Rosemount 3051SFP Integral Orifice Flowmeter

Emerson Rosemount Integral Orifice Flowmeters and Primary Elements

3051SFP, 3095MFP, 3051CFP, 2051CFP, 1195

The Emerson Rosemount Integral Orifice Flowmeter assembly is designed to meet the need for highly accurate small bore flow measurements with minimal installation and maintenance requirements.
The Rosemount 1195 is suitable for measurement of any clean gas, liquid, or vapor flow. It can be directly mounted to any Rosemount differential pressure transmitter and used in many environments and applications.
Available preassembled to the world's most popular pressure transmitters
Gasket groove and self-centering orifice plate design to prevent installation errors
Numerous process connections and construction material options
Wide orifice bore/flow range capability
Compliant with NACE MR-0175
Emerson Rosemount Integral Orifice Flowmeters offer highly accurate small-bore flow measurement capability with minimal installation and maintenance requirements.
Improves accuracy and repeatability in 1/2-in., 1-in., and 1 1/2-in. line sizes
Reduces leak points by over 50% and minimizes line plugging
Improves reliability with consistent installations
Multivariable measurement for gas and steam
Integral Orifice Assemblies

The Rosemount Intgral Orifice Flowmeter provides high accuracy in small line size applications. A self-centering plate, precision honed pipe section and tight machining tolerances ensure higher installed performance. Numerous process connections are available for flexible installaion.
Precision Installation in Small Lines

Integrated Flowmeter	Rosemount 3051SFP with Measurement Types 1-4	Rosemount 3051SFP Measurement Type D
Accuracy	•Mass flow up to 0.8% of mass flow rate, 14:1 turndown •Classic MV up to ±0.85 % of flow rate, 8:1 flow turndown	•Volumetric flow up to 0.8% of volumetric flow rate, 14:1 turndown •Classic MV up to ±0.85% of volumetric flow rate, 8:1 turndown
Repeatability	± 0.1 %	± 0.1 %
Output	•4-20mA signal based on HART® Communication •WirelessHART with Smart Wireless THUM adapter	•4-20mA signal based on HART® Communication •WirelessHART •FOUNDATION™ fieldbus
Long Term Stability	Up to 15-year stability	Up to 15-year stability
Warranty	Up to 15-year limited warranty	Up to 15-year limited warranty
Diagnostics	•User-writable process temperature sensor limits •Sensor Temperature as an output •Instant Flow Verification	Advanced HART Diagnostic Suite
Line Size	½-in (15 mm) 1-in (25 mm) 1 ½-in (40 mm)	½-in (15 mm) 1-in (25 mm) 1 ½-in (40 mm)
Complete Specifications (PDF @ 2.42Mb)

Primary Element	1195 Integral Orifice
Service	Liquid, Gas, Steam
Accuracy	Up to ±0.75% of flow rate
Process Temperature Limits	Standard (direct/remote mount): • -40 to 450 °F (-40 to 232 °C) Extended (remote mount only with option code G): • -148 to 850 °F (-100 to 454 °C)
Line Sizes	½-in (15 mm) 1-in (25 mm) 1 ½-in (40 mm)
